ACR-0800 Autonomous Ride-On Floor Scrubber

Large-Area Scrubbing

ACR-0800 Autonomous Ride-On Floor Scrubber

The ACR-0800 is a driverless commercial floor scrubber built for large-area cleaning. With an 800 mm scrubbing path, 1,160 mm sweeping width and up to 4,000 m²/h, it carries a 140 L clean-water tank and a 36 V / 200 Ah LiFePO₄ battery for 4–6 hours of continuous work — suitable for transport hubs, plazas, shopping centres and other large hard-floor environments.

4,000m²/h max. capacity
4–6 hruntime per charge
800 mmscrubbing width
140 Lclean-water tank

What it solves

Built around real site constraints

/01
4,000 m²/h of cleaning capacity

An 800 mm scrubbing path, 1,160 mm sweeping width and 1,024 mm squeegee let a single machine cover tens of thousands of square metres in routine operation.

/02
140 L tank means fewer interruptions

The large clean-water tank paired with 4–6 hours of runtime significantly reduces mid-shift refilling and operator intervention.

/03
Sweep, scrub and dry in one pass

Sweeping, scrubbing and water recovery are completed in a single pass, eliminating repeat runs over the same floor.

/04
Fully autonomous navigation

LiDAR, depth cameras and ultrasonic sensors are fused for environment perception, automatic path planning and obstacle recognition — no floor QR codes or magnetic tape required.

/05
36 V / 200 Ah LiFePO₄ battery

A high-capacity lithium iron phosphate pack provides long cycle life and high safety for demanding, continuous duty.

/06
Optional spraying function

An optional spray tank adds on-site spraying, providing a complete one-stop hard-floor cleaning solution.

Best-fit applications

Use these applications as the first filter, then send your route, floor material and operating schedule for model confirmation.

Airports & transport hubsPlazas & paved outdoor areasShopping mallsExhibition & sports venuesIndustrial plants & large warehousesCar parks

ACR-0800

Technical specifications

Dimensions (L×W×H)1,340 × 1,024 × 1,350 mm
Weight400 kg
OperationSweeping + scrubbing + water recovery in one pass (spraying optional)
Max. cleaning capacity4,000 m²/h
Scrubbing width800 mm
Sweeping width1,160 mm
Squeegee width1,024 mm
Clean-water tank140 L
Battery typeLithium iron phosphate (LiFePO₄)
Voltage / capacity36 V / 200 Ah
Runtime per charge4 – 6 hours
NavigationFully autonomous driving with automatic path planning
Sensor suiteLiDAR + depth camera + ultrasonic radar, multi-sensor fusion
Core capabilityEnvironment perception, automatic path planning, obstacle recognition and avoidance
EnvironmentLarge and medium indoor and outdoor hard floors
Suitable floorsHard floors — marble, terrazzo, ceramic tile, epoxy, concrete and similar

Specifications are based on the latest PanPanTech product specification document. Final configuration should be confirmed through the website contact form.

Share your floor plan or material-flow route.

For more product details, accessory options and deployment planning, contact PanPanTech through the website form or listed contact information.

Open contact form
